Hendrickson
Showing 1–24 of 27 results
-
Air Controls, Heavy Truck, Lift Axle, Non Steering, Self Steering
LC-SSI_R2 Hendrickson Air Control Kit for Steer & Non-Steer Lift Axles
On Sale!
*FREE UPS Ground
on orders of $99 or more!USA!
Air Controls, Heavy Truck, Lift Axle, Non Steering, Self SteeringLC-SSI_R2 Hendrickson Air Control Kit for Steer & Non-Steer Lift Axles
AVAILABLE NOW!
Genuine LC-SSI Hendrickson Air Control Kit replaces existing HAC-SSI and HAC-NSI auxiliary lift axle control kits with a change in air line plumbing. The panel has exactly the same measurements as the HAC series, 2-3/4 x 7-1/4 with a bolt pattern of 2.25 x 6-5/8.
- Lift in reverse application (can be used in a non-steer application by not wiring the solenoid).
- Note: A electrical relay may be required to connect to the reverse light circuit for the “lift in reverse” feature. Download the installation instructions below for more details.
- 12vdc applied to the lift solenoid raises the axle. This would be typically connected to the reverse light circuit. Axle lowers when power is removed.
- Note that some vehicles use a negative switched reverse light circuit and would require the use of a relay to operate properly (not included).
- 12vdc applied to the lift solenoid raises the axle. This would be typically connected to the reverse light circuit. Axle lowers when power is removed.
- Note: A electrical relay may be required to connect to the reverse light circuit for the “lift in reverse” feature. Download the installation instructions below for more details.
- Hendrickson Part Number B-38914-2 (LC-SSI_R2 )
- LC-SSI_R2 Supecedes LC-SSI
- This kit is for lifting/lowering the suspension only and does not control brakes.
SKU: HL-LC-SSI_R2 - Lift in reverse application (can be used in a non-steer application by not wiring the solenoid).
-
Heavy Truck, Suspension, Air Springs
R-B-14486 Lift Bag (air spring) Paralift Ultra
*FREE UPS Ground
on orders of $99 or more!Heavy Truck, Suspension, Air SpringsR-B-14486 Lift Bag (air spring) Paralift Ultra
R-B-14486 Lift Bag (air spring) Paralift Ultra
Lift bag for Hendrickson HLU, HLS, HLN, HLUS Suspensions.
Hendrickson Trailer and Hendrickson Aux. S14486 lift bag (Paralift, Paralift Ultra)
- 257C or 20 on rubber
- Same as S-14486
SKU: M-FS7795 -
Heavy Truck, Lift Axle, Repair Parts, Steering Stabilizer Shocks, Shock Absorbers
R-009600 Hendrickson Lift Axle Stabilizer Shock
*FREE UPS Ground
on orders of $99 or more!Heavy Truck, Lift Axle, Repair Parts, Steering Stabilizer Shocks, Shock AbsorbersR-009600 Hendrickson Lift Axle Stabilizer Shock
This shock a OEM Hendrickson part. It fits some Composilite SC applications (SCT10/13) and others.
- Hendrickson right to substitute notice 3/29/2021 (alternative suppliers, same part number)
- Some shocks may have 009600-2 stamped on side.
Sold each with a minimum qty of 2.
SKU: HL-R-009600 -
Air Controls, Air Valves & Parts, Heavy Truck, Lift Axle, Pressure Protection Valves
R-017521-13 Pressure Protection Valve 1/4NPT 70psi
*FREE UPS Ground
on orders of $99 or more!USA!
Air Controls, Air Valves & Parts, Heavy Truck, Lift Axle, Pressure Protection ValvesR-017521-13 Pressure Protection Valve 1/4NPT 70psi
R-017521-13 Pressure Protection Valve 1/4NPT 70psi
- Ports 1/4 in NPTF
- Pressure 200 psi max. supply, Not Adjustable
- Pressure to open 75 psi
- Pressure to close 70 psi
OE Numbers:
- Replaces the following numbers:
- PVN447
- VS38941
- VS-38941
- B38941
- B-38941
- VS1128
- VS-1128
SKU: HL-R-017521-13 -
Bushing Kits, Heavy Truck, Lift Axle, Repair Parts
334-1589 Hendrickson Paralift Wear Washer
*FREE UPS Ground
on orders of $99 or more!USA!
Bushing Kits, Heavy Truck, Lift Axle, Repair Parts334-1589 Hendrickson Paralift Wear Washer
334-1589 Hendrickson Paralift Wear Washer
When you replace your Hendrickson Paralift Beams, don’t forget the Wear Washer!
- Used in R-002006-2 and R-002006-2 Beams.
- 4 Required for each beam.
Specs:
- 4.25” Outside
- 2.25” Inside
- .190 Thick
SKU: DP-334-1589 -
Bushing Kits, Heavy Truck, Lift Axle, Repair Parts
334-1862 Hendrickson Paralift Bolt Kit
*FREE UPS Ground
on orders of $99 or more!USA!
Bushing Kits, Heavy Truck, Lift Axle, Repair Parts334-1862 Hendrickson Paralift Bolt Kit
334-1862 Hendrickson Paralift Bolt Kit
When you replace your Hendrickson Paralift Beams, don’t forget the bolt kits!
- Used in R-002006-2 and R-002006-2 Beams.
- Each Bolt Kit includes one delrin sleeve, bolt & locknut, and 2 washers. Enough to do one bushing.
Bolt Kit Specs:
- (1) Lock Nut ST 7/8in GR 8
- (2) USS Iron Flat Washer 7/8in
- (1) Cap Screw 7/8in X7-1/2in GR8
- (1) Delrin Sleeve Hendrickson 1” inside x .875” inside x 5” long.
Sold in quantities of each bolt kit x 2. (Picture shows 2 kits.)
SKU: DP-334-1862 -
Bushing Kits, Heavy Truck, Lift Axle, Repair Parts
R-002237 Hendrickson Paralift Bushing Assy
*FREE UPS Ground
on orders of $99 or more!USA!
Bushing Kits, Heavy Truck, Lift Axle, Repair PartsR-002237 Hendrickson Paralift Bushing Assy
R-002237 Hendrickson Paralift Bushing Assy
Replace your worn Hendrickson trailing beam bushingss. Price is for each bushing kit.
- Used in R-002006-2 and R-002006-2 Beams
- Kit includes one bushing, delrin sleeve, bolt & locknut, and 2 washers.
- This kit has the same bushing kit used in Hendrickson total rebush kit R-009560.
- Eight of this number R-002237 equals one of a R-009560.
Kit Specs:
- (1) Bushing; 1 1/32″ID x 3 3/8″OD x 5 1/4″Lg
- (1) Lock Nut ST 7/8in GR 8
- (2) USS Iron Flat Washer 7/8in
- (1) Cap Screw 7/8in X7-1/2in GR8
- (1) Delrin Sleeve Hendrickson 1” inside x .875” inside x 5” long.
- (2) Hendrickson Paralift Wear Washer: 4.25” Outside x 2.25” Inside x .190 Thick
SKU: DP-334-1588 -
Air Tanks, Heavy Truck, Lift Axle, Miscellaneous, Repair Parts
R-004687 Hendrickson Air Tank Bracket Kit
On Sale!
*FREE UPS Ground
on orders of $99 or more!Air Tanks, Heavy Truck, Lift Axle, Miscellaneous, Repair PartsR-004687 Hendrickson Air Tank Bracket Kit
Replace your broken air tank brackets with this OE Hendrickson kit.
Components:
- (4) Straps.
- (2) 3/8 Clamp Bolts with Nuts.
Item commonly used with:
- Hendrickson R-004686 Air Tank which is 9.5in in diameter and 22.68in in length.
- Also included in R-004688 Hendrickson air tank kit.
SKU: HL-R-004687 -
Heavy Truck, Lift Axle, Repair Parts, Beams
R-008940 Hendrickson Composilite SC 13k Beam Assembly
On Sale!
*FREE UPS Ground
on orders of $99 or more!USA!
Heavy Truck, Lift Axle, Repair Parts, BeamsR-008940 Hendrickson Composilite SC 13k Beam Assembly
R-008940 Hendrickson Composilite SC 13k Beam Assembly
Replace your worn or broken Hendrickson trailing beams. Price is for each beam including bushings.
- This OE beam fits both sides & upper/lower.
- Bushing width is 3 inches.
- Beam length center of bushing to center of bushing is 16.8 inches.
- Bushing fits a 3/4in bolt.
- Does not include bolts, nuts or washers.
SKU: HL-R-008940 -
Heavy Truck, Lift Axle, Air Controls, Air Valves & Parts
R-017521-04 Hendrickson Regulator 1/4 NPT Ports
*FREE UPS Ground
on orders of $99 or more!USA!
Heavy Truck, Lift Axle, Air Controls, Air Valves & PartsR-017521-04 Hendrickson Regulator 1/4 NPT Ports
This R-017521-04 Hendrickson Regulator with 1/4 NPT Ports is used in applications using the Hendickson LC Series control panels.
1/4” NPT Ports, 12vdc, 3-Way
REGULATOR NUT #R-017521-20 IS NOT INCLUDED.
Applications;
- LC-NSI
- LC-SSI
SKU: HL-R-017521-04 -
Heavy Truck, Air Switch, Lift Axle, Air Controls, Air Valves & Parts
R-017521-06 Hendrickson Air Toggle Switch
On Sale!
*FREE UPS Ground
on orders of $99 or more!USA!
Heavy Truck, Air Switch, Lift Axle, Air Controls, Air Valves & PartsR-017521-06 Hendrickson Air Toggle Switch
This Pneumatic Toggle Switch is used in applications using the Hendickson LC Series control panels.
1/4” Push to connect fittings on each side for DOT nylon air hose.
Applications;
- LC-NSI
- LC-SSI
SKU: HL-R-017521-06 -
Heavy Truck, Gauges, Lift Axle, Air Controls, Air Valves & Parts
R-017521-08 Hendrickson 2” Liquid Filled Air Guage
*FREE UPS Ground
on orders of $99 or more!USA!
Heavy Truck, Gauges, Lift Axle, Air Controls, Air Valves & PartsR-017521-08 Hendrickson 2” Liquid Filled Air Guage
This R-017521-08 Hendrickson 2” Liquid Filled Air Guage is used in applications using the Hendickson LC Series control panels.
Includes 1/4” Push to connect fitting on for DOT nylon air hose.
Applications;
- LC-NSI
- LC-SSI
- ASI
SKU: HL-R-017521-08 -
Air Controls, Air Valves & Parts, Heavy Truck, Lift Axle, Solenoid Valves
R-017521-12 Hendrickson Solenoid Valve 12vdc
*FREE UPS Ground
on orders of $99 or more!USA!
Air Controls, Air Valves & Parts, Heavy Truck, Lift Axle, Solenoid ValvesR-017521-12 Hendrickson Solenoid Valve 12vdc
This R-017521-12 Hendrickson Solenoid Valve 12vdc is used in applications using the Hendickson LC Series control panels.
1/4” NPT Ports, 12vdc, 3-Way
Applications;
- LC-NSI
- LC-SSI
- ASI
SKU: HL-R-017521-12 -
Heavy Truck, Lift Axle, Air Controls, Panel Mounting Brackets
R-005771 Hendrickson Inside Single L Bracket Kit
*FREE UPS Ground
on orders of $99 or more!USA!
Heavy Truck, Lift Axle, Air Controls, Panel Mounting BracketsR-005771 Hendrickson Inside Single L Bracket Kit
Mount your Hendrickson lift axle panel under-dash, or side mount with this “L” mounting bracket. This is for a single panel application.
Fits:
- LC-SSI
- LC-SSI_R2
- LC-NSI
- LC-NSI_R2
SKU: HL-R-005771
