B3000301

B3000-301 AIRman Tail-a-Gater Tailgate Cylinder with Mounting Bracket

• SINGLE ACTING CYLINDER

Special Order.

Specs:

• Model Number: B3000-301
• Mounting bolt spacing 3.50in
• Stamped with letter “K” on end
• SINGLE ACTING
• MOUNTING BRACKET AND SPRING LOAD TO MATCH MGM P/N 5005012
• Bore Size: 6.00in
• Cylinder Length: 11.12in measuring from center of mounting plate swivel bolts to end of cylinder
• Stroke: 4.38in
• Extended Rod Length: 16.48in measuring from center of mounting plate swivel bolts to end of rod
• Collapsed Rod Length: 12.10in measuring from center of mounting plate swivel bolts to end of rod
• Rod Size: 5/8-18 in
• Rod Thread Length: 6.00in
• Supply port 1/4NPT
• Air inlet is on the back plate. Vent is on the pushrod side.
