TRB3.50X8.58 AIRman 3.5in Air Cylinder 8.58in Stroke

TRB3.50X8.58 AIRman 3.5in Air Cylinder 8.58in Stroke

This AIRman 3.5-inch air cylinder is engineered for high-performance industrial applications requiring a precise 8.58-inch stroke. Critically, the cylinder is built using an anodized aluminum tube and a lightweight aluminum piston to reduce overall weight without sacrificing strength. Furthermore, the piston features a built-in UHMW wear band to minimize friction and extend the operational life of the unit.

Environmental & Compliance Standards

• Extreme Temperatures: To ensure reliability, the cylinder utilizes specialized -65°F nitrile seals.
• Simultaneously, it is packed with premium -75°F silicone grease to guarantee smooth operation in freezing conditions.
• Material Regulation: Regarding safety standards, all components are fully compliant with the most current revisions of RoHS and REACH directives.
• Consequently, this item guarantees a strict reduction of hazardous substances and materials.

Hardware & Mounting Integration

• Included Components: By default, the unit comes equipped with a 1/2-inch clevis pin and a cotter pin for the cylinder end.
• Missing Components: Conversely, please note that the clevis for the rod is not included in this package.
• Thread Specifications: For installation purposes, the rod features precision-cut 5/8” – 18 UNF threads to accommodate your mounting hardware.

Technical Specifications

• Bore Diameter: 3.50 inches
• Stroke Length: 8.58 inches
• Rod Threading: 5/8” – 18 UNF
• Cylinder Pin Size: 1/2 inch

OE Numbers:

None

Drawing / Dimensions:

• TRB3.50XSTROKE CUSTOMER TABLE PRINT REV E
