Air Cylinders
Showing all 12 results
-
Air Cylinders, Air Supply, Heavy Truck
B3000-259-H-5 AIRman Tail-a-Gater Tailgate Cylinder
On Sale!
*FREE UPS Ground
on orders of $99 or more!USA!
Air Cylinders, Air Supply, Heavy TruckB3000-259-H-5 AIRman Tail-a-Gater Tailgate Cylinder
B3000-259-H-5 (w/5 inch rod) AIRman Tail-a-Gater Tailgate Cylinder is made from heavy duty aluminum thick wall tubing with pivoting trunnion flange for harsh conditions.
Does NOT include clevis and is exactly as pictured (rod extended). Drawing below & in Specs.
OE Numbers:
- MAC Trailer 27080090
- 2190022
- PB3000
- T212703259
Specs:
- Model Number: B3000-259-H5
- Bore Size: 6.00in
- Cylinder Length: 7-7/8in
- Stroke: 3.00in
- Extended Rod Length: 5in (Measuring from flat studded plate to end of rod)
- Rod Size: 5/8in
- Air inlet is on the back plate. Vent is on the pushrod side.
SKU: AP-B3000-259-H-5 -
Air Cylinders, Air Supply, Heavy Truck
B3000-259-H-6.5 AIRman Tail-a-Gater Tailgate Cylinder
On Sale!
*FREE UPS Ground
on orders of $99 or more!USA!
Air Cylinders, Air Supply, Heavy TruckB3000-259-H-6.5 AIRman Tail-a-Gater Tailgate Cylinder
B3000-259-H-6.5 (w/6.5 inch rod) AIRman Tail-a-Gater Tailgate Cylinder is made from heavy duty aluminum thick wall tubing with pivoting trunnion flange for harsh conditions.
Does NOT include clevis and is exactly as pictured (rod extended). Drawing below & in Specs.
OE Numbers:
- East Mfg. 510-25950-03 (cylinder only)
- Velvac 100603
- MAC Trailer 27080091
Specs:
- Model Number: B3000-259-H6.5
- Bore Size: 6.00in
- Cylinder Length: 7-7/8in
- Stroke: 3.00in
- Extended Rod Length: 6.50in (Measuring from flat studded plate to end of rod)
- Rod Size: 5/8in
- Air inlet is on the back plate. Vent is on the pushrod side.
SKU: AP-B3000-259-H-6.5 -
Air Cylinders, Air Supply, Heavy Truck
B3000-424 AIRman 2in Air Cylinder 3in Stroke
On Sale!
*FREE UPS Ground
on orders of $99 or more!USA!
Air Cylinders, Air Supply, Heavy TruckB3000-424 AIRman 2in Air Cylinder 3in Stroke
B3000-424 AIRman 2in Air Cylinder 3in Stroke
AIR CYLINDER, 2.0 X 3.0 STROKE, SPRING EXT., DOUBLE ACTING
Drawing below & in Specs.
OE Numbers:
- AKW381140A0
- ACKW381140A0
Specs:
- Model Number: B3000-424
- Bore Size: 2.00in
- Stroke: 3.00in
- Extended Rod Length: 15.0 in from center of clevis eye to eye
- Collapsed Rod Length: 12.0 in from center of clevis eye to eye
- Clevis Eye Hole Diameter: .625 in
- Rod Diameter: 1 in
SKU: AP-B3000-424 -
Air Cylinders, Air Supply, Heavy Truck
B3000-425 AIRman 2.5in Air Cylinder 4.13in Stroke
On Sale!
*FREE UPS Ground
on orders of $99 or more!USA!
Air Cylinders, Air Supply, Heavy TruckB3000-425 AIRman 2.5in Air Cylinder 4.13in Stroke
B3000-425 AIRman 2.5in Air Cylinder 4.13in Stroke
AIR CYLINDER, 2.50 BORE x 4.125 STROKE, DOUBLE-ACTING
Drawing below & in Specs.
Specs:
- Model Number: B3000-425
- Bore Size: 2.5in
- Stroke: 4.125in
- Extended Rod Length: 15.63 in from center of clevis eye to end of push rod
- Collapsed Rod Length: 11.5 in from center of clevis eye to end of push rod
- Clevis Eye Hole Diameter: .5 in
- Rod Diameter: 1 in
OE Numbers:
- ACKW381140B0
Drawing / Dimensions:
SKU: AP-B3000-425 -
Air Cylinders, Air Supply, Heavy Truck
B3000-517 AIRman 3.5in Air Cylinder 8in Stroke
On Sale!
*FREE UPS Ground
on orders of $99 or more!USA!
Air Cylinders, Air Supply, Heavy TruckB3000-517 AIRman 3.5in Air Cylinder 8in Stroke
B3000-517 AIRman 3.5in Air Cylinder 8in Stroke
AIR CYLINDER, 3.50 BORE x 8 STROKE, DOUBLE-ACTING
Drawing below & in Specs.
Specs:
- Model Number: B3000-517
- Bore Size: 3.5in
- Stroke: 8in
- Extended Rod Length: 20.50 in from center of clevis eye to center of clevis eye
- Collapsed Rod Length: 12.5 in from center of clevis eye to center of clevis eye
- Clevis Eye Hole Diameter: 1 in both ends with brass bushings
- Rod Diameter: 1-1/8 in
- Includes two 1in clevis pins
OE Numbers:
- None
SKU: AP-B3000-517 -
Air Cylinders, Air Supply, Heavy Truck
B3000-301 AIRman Tail-a-Gater Tailgate Cylinder w/Bkt
*FREE UPS Ground
on orders of $99 or more!USA!
Air Cylinders, Air Supply, Heavy TruckB3000-301 AIRman Tail-a-Gater Tailgate Cylinder w/Bkt
B3000-301 AIRman Tail-a-Gater Tailgate Cylinder with Mounting Bracket
- SINGLE ACTING CYLINDER
Special Order.
Specs:
- Model Number: B3000-301
- SINGLE ACTING
- MOUNTING BRACKET AND SPRING LOAD TO MATCH MGM P/N R5AHD.
- Bore Size: 6.00in
- Cylinder Length: 9.68in (or 11.12in measuring from center of through bolt on mounting bracket to end of cyl)
- Stroke: 4.38in
- Extended Rod Length: 16.58in (Measuring from center of through bolt on mounting bracket to end of rod)
- Rod Size: 5/8in
- Rod Thread Length: 10.75in
- Supply port 1/4NPT
- Air inlet is on the back plate. Vent is on the pushrod side.
SKU: AP-B3000-301 -
Air Cylinders, Air Supply, Heavy Truck
B3000-379 AIRman Tail-a-Gater Tailgate Cylinder w/Bkt
*FREE UPS Ground
on orders of $99 or more!USA!
Air Cylinders, Air Supply, Heavy TruckB3000-379 AIRman Tail-a-Gater Tailgate Cylinder w/Bkt
B3000-379 AIRman Tail-a-Gater Tailgate Cylinder with Mounting Bracket
- DOUBLE ACTING CYLINDER
Specs:
- Model Number: B3000-301
- DOUBLE ACTING
- SPRING LOAD TO MATCH MGM P/N 5005012
- Bore Size: 6.00in
- Cylinder Length: 9.68in (or 11.12in measuring from center of through bolt on mounting bracket to end of cyl)
- Stroke: 4.38in
- Extended Rod Length: 16.38in (Measuring from center of through bolt on mounting bracket to end of rod)
- Rod Size: 5/8in
- Rod Thread Length: 6.00in
- Supply port 1/4NPT
- Air inlet is on the back plate. Vent is on the pushrod side.
SKU: AP-B3000-379 -
Air Cylinders, Air Supply, Heavy Truck
RCB3.50X10.00 AIRman 3.5in Air Cylinder 10in Stroke
*FREE UPS Ground
on orders of $99 or more!USA!
Air Cylinders, Air Supply, Heavy TruckRCB3.50X10.00 AIRman 3.5in Air Cylinder 10in Stroke
RCB3.50X10.00 AIRman 3.5in Air Cylinder 10in Stroke
See Drawing Below.
Specs:
- 3.50″ Bore X 10” Stroke Cylinder
- 1/2 inch Clevis Pin and Cotter Pin for Cylinder End Included
- Clevis for the rod is NOT included.
- 5/8” – 18 UNF threads on rod.
Short lead time. If this is a rush order, please call us.
SKU: AP-RCB3.50X10.00 -
Air Cylinders, Air Supply, Heavy Truck
TR2.50×6.00 AIRman 2.5in Air Cylinder 6in Stroke
*FREE UPS Ground
on orders of $99 or more!USA!
Air Cylinders, Air Supply, Heavy TruckTR2.50×6.00 AIRman 2.5in Air Cylinder 6in Stroke
TR2.50×6.00 AIRman 2.5in Air Cylinder 6in Stroke
See Drawing Below.
Specs:
- 2.5″ Bore X 6” Stroke Cylinder
- 1/2 inch Clevis Pin and Cotter Pin for Cylinder End Included
- Clevis for the rod is NOT included.
- 5/8” – 18 UNF threads on rod.
Short lead time. If this is a rush order, please call us.
SKU: AP-TR2.50X6.00 -
Air Cylinders, Air Supply, Heavy Truck
TR2.50×8.00 AIRman 2.5in Air Cylinder 8in Stroke
*FREE UPS Ground
on orders of $99 or more!USA!
Air Cylinders, Air Supply, Heavy TruckTR2.50×8.00 AIRman 2.5in Air Cylinder 8in Stroke
TR2.50×8.00 AIRman 2.5in Air Cylinder 8in Stroke
See Drawing Below.
Specs:
- 2.5″ Bore X 8” Stroke Cylinder
- 1/2 inch Clevis Pin and Cotter Pin for Cylinder End Included
- Clevis for the rod is NOT included.
- 5/8” – 18 UNF threads on rod.
Short lead time. If this is a rush order, please call us.
SKU: AP-TR2.50X8.00 -
Air Cylinders, Air Supply, Heavy Truck
TR4.00×24.00 AIRman 4in Air Cylinder 24in Stroke
*FREE UPS Ground
on orders of $99 or more!USA!
Air Cylinders, Air Supply, Heavy TruckTR4.00×24.00 AIRman 4in Air Cylinder 24in Stroke
TR4.00×24.00 AIRman 4in Air Cylinder 24in Stroke
Limited supply, to be obsolete when stock is depleted.
See Drawing Below.
Specs:
- 4″ Bore X 24” Stroke Cylinder
- 1 inch Clevis Pin and Cotter Pin for Cylinder End Included
- Clevis for the rod is NOT included.
- 1-1/8” – 12 UNF threads on rod.
Short lead time. If this is a rush order, please call us.
SKU: AP-TR4.00x24.00
